IPC400-H470 工控机 4U上架式工控机

特点:

支持Intel® 10/11th Generation Core/Pentium/Celeron Desktop CPU
全套模具成型，标准19英⼨4U上架式机箱
安装标准ATX主板，支持标准4U电源
最多支持7槽位全高卡扩展，满足多行业应用需求
人性化设计，机箱前置系统风扇免工具维护
精心设计的免工具PCIe扩展卡固定架、具有更高的抗震性
最多可选8个3.5英寸抗震抗冲击硬盘位
可选2个5.25英寸光驱安装盒
前⾯板USB、开关机设计，电源及存储状态显⽰，更易于系统维护
支持非法开箱报警，可锁前门，防止未经许可的访问

远程管理
状态监控
远程运维
安全控制

联系我们

扫码即可添加微信，售前客服为您提供咨询服务

产品介绍

工程图纸

下载产品资料

扫码添加微信，获取最新产品资料文件

Model	IPC400-H470
Processor System	CPU	Support Intel^® 10/11th Generation Core / Pentium/ Celeron Desktop CPU
	TDP	125W
	Socket	LGA1200
	Chipset	H470
	BIOS	AMI 256 Mbit SPI
Memory	Socket	2 * Non-ECC U-DIMM Slot, Dual Channel DDR4 up to 2933MHz
	Capacity	64GB, Single Max. 32GB
Graphics	Controller	Intel® HD Graphics
Ethernet	Controller	1 * Intel i225-V LAN Chip (10/100/1000/2500 Mbps, RJ45) 1 * Intel i219-LM GBE LAN Chip (10/100/1000 Mbps, RJ45)
Storage	SATA	3 * SATA3.0 7P Connector
	M.2	1 * M.2 Key-M Slot (PCIe 3.0 x4 + SATA 3.0, NVMe/ SATA SSD Auto Detect, 2242/2260/2280)
Expansion Slots	PCIe	1 * PCIe x16 slot (Gen 3, x16 signal) 1 * PCIe x4 slot (Gen 3, x1 signal) 1 * PCIe x4 slot (Gen 3, x1 signal)
	PCI	4 * PCI slot
	Mini PCIe	1 * Mini PCIe (PCIe 3.0x1+USB 2.0, with 1 * SIM Card slot)
Front I/O	Ethernet	2 * RJ45
	USB	4 * USB 5Gbps (Type-A, 5Gbps, 2 ports for a total of 3A) 2 * USB2.0 (Type-A, 2 ports for a total of 2A)
	PS/2	1 * PS/2 (Keyboard & Mouse)
	Display	1 * DVI-D: max resolution up to 19201200 @ 60Hz 1 HDMI1.4: max resolution up to 3840*2160 @ 30Hz
	Audio	3 * 3.5mm Jack (Line-out + Line-in + MIC)
	Serial	2 * RS232/422/485 (COM1/2, DB9/M, Full Lanes, BIOS Switch)
Rear I/O	USB	2 * USB2.0 (Type-A)
	Button	1 * Power Button
	LED	1 * Power status LED 1 * Hard drive status LED
Internal I/O	USB	2 * USB 5Gbps (F_USB3, wafer) 1 * USB2.0 (USB2_1, Vertical type connector) 2 * USB2.0 (F_USB2_1, header)
	COM	4 * RS232 (COM3/4/5/6, Header, Full Lanes)
	Display	1 * VGA: max resolution up to 19201200 @ 60Hz (wafer) 1 eDP: max resolution up to 1920*1200 @ 60Hz (Header)
	Audio	1 * Front Audio (Line-Out + MIC, Header) 1 * Speaker (3W (per channel) into a 4Ω Loads, wafer)
	GPIO	1 * 16 bits DIO (8DI and 8DO, wafer)
	SATA	3 * SATA 7P Connector
	LPT	1 * LPT (Header)
	FAN	2 * SYS FAN (Header) 1 * CPU FAN (Header)
Power Supply	Type	ATX
	Power Input Voltage	AC power supply, voltage and frequency shall be based on the ATX power supply provided
	RTC Battery	CR2032 Coin Cell
OS Support	Windows	Windows 10/11
	Linux	Linux
Watchdog	Output	System Reset
	Interval	Programmable 1 ~ 255 sec
Mechanical	Enclosure Material	SGCC
	Dimensions	482.6mm(L) * 464.5mm(W) * 177mm(H)
	Mounting	Shelf mounted installation
Environment	Heat Dissipation System	PWM fan cooling
	Operating Temperature	0 ~ 50℃
	Storage Temperature	-20 ~ 70℃
	Relative Humidity	10 to 95% RH (non-condensing)
